Best Projector Screen for Epson LS800 & EH-TW7820
Shop the screens in this guide
View all UST Screens →
Epson's LS800 and EH-TW7820 are both excellent 4K projectors — but they're fundamentally different types, and each needs a completely different screen. Getting this wrong is costly. Here's exactly what each requires.
Epson LS800 — Ultra-Short Throw Laser
The LS800 is a 4K UST laser projector with 4,000 lumens and a 0.16:1 throw ratio. It sits on a credenza, TV stand, or purpose-built shelf within 10–25 cm of the wall and projects upward. With that level of brightness — the highest in its class — it's particularly capable in rooms that can't be fully blacked out.
Because of the extreme projection angle, the LS800 requires a UST Fresnel ALR screen. Fresnel screens use micro-optical ridges to capture steeply angled light from below and redirect it toward viewers, simultaneously blocking overhead light from ceiling fixtures. On a standard screen, the LS800's image will look flat, dim, and washed out regardless of the projector settings.
Best screens for the Epson LS800
TrueThrow Fresnel ALR UST Screen — Best overall for LS800
Gain 2.0 or 2.5, 130° viewing cone. The LS800's high lumen output pairs exceptionally well with this screen — 4,000 lumens at gain 2.0 or 2.5 delivers a noticeably bright image even with blinds open. The Fresnel structure provides the strongest ambient-light rejection of any TrueThrow UST screen. Available 80"–120".
TrueThrow CBSP Carbon Black UST Screen — Best for dark rooms
Gain 0.6, 160° viewing angle. The LS800's 4,000 lumens is more than enough headroom even at 0.6 gain — you'll still have a bright, vivid image while gaining significantly deeper blacks than any Fresnel screen. Choose this if your room has good light control and cinema-quality contrast is the priority.
TrueThrow PET Crystal BSP UST Screen — Widest viewing angle
Gain 0.6, 170° viewing angle — the widest of any TrueThrow UST screen. If your space has viewers seated at sharp side angles (wide seating arrangement, open-plan room), this screen maintains consistent brightness further off-axis than any Fresnel-based screen.
Epson EH-TW7820 — Standard Throw 4K 3LCD
The EH-TW7820 is a 4K 3LCD standard throw projector rated at 2,800 lumens with a throw ratio of 1.22:1–2.47:1. It mounts on a ceiling or shelf 2–4 metres from the screen — this is a traditional projector that works with traditional screens.
Best screens for the Epson EH-TW7820
TrueThrow Matte White Screen — Best for dark rooms
Gain 1.1, 160° viewing angle. The EH-TW7820's 3LCD engine produces excellent colour accuracy on a neutral matte white surface — you get the projector's full colour gamut without any screen-induced bias. For a dedicated cinema room or light-controlled space, this is the purest image.
TrueThrow Grey Crystal ALR Screen — Best for mixed lighting
Gain 1.0, 160° viewing angle. The angular ALR coating reflects the projector's straight-on light efficiently while absorbing side-angle ambient light. If you watch in a living room with windows or lights on, this screen produces visibly better contrast than matte white without any colour shift.
TrueThrow Black Crystal ALR Screen — Best for bright rooms
Gain 0.8, 160° viewing angle. The strongest ambient-light rejection in the fixed-frame range. The EH-TW7820's 2,800 lumens is sufficient at 0.8 gain on screens up to 130" — and you gain noticeably deeper blacks than any lighter-surfaced screen.
Size Recommendations
Epson LS800: 100"–110" is the sweet spot. The projector's 4,000 lumens handles up to 120" comfortably even with ambient light.
Epson EH-TW7820: Match the size to your throw distance. At 3 metres, a 110"–120" screen is typical. Use a throw distance calculator if you're between sizes — a screen that's too large for the room's lighting will look dim at the edges.
